12V/3.0Kg-cm/78RPM 51:1 DC Gear Motor w/Encoder

ID: 3263E_0
This DC motor has an encoder, a 51:1 gearbox, a rated speed of 78 RPM and rated torque of 3.06 Kg·cm.

Replaced by 3263E_1

Replaced by the 3263E_1 – 12V/3.0Kg-cm/78RPM 51:1 DC Gear Motor w/Encoder

The 3263E is a 12 volt gear motor, generating 3.06 Kg-cm of torque at 78 RPM. This motor is quite compact considering the amout of power it can output.

This motor comes equipped with an E4P US Digital Encoder, which keeps track of the motor's rotation, allowing you to control your motor precisely.

The planetary gearbox on this motor is more sophisticated than a typical spur gearbox and will provide greater efficiency, higher torque, and quieter motor operation.


Comes packaged with

Product Specifications

Motor Properties
Motor Type DC Motor with Encoder
Output Power (Mechanical) 2.9 W
Maximum Speed at Rated Voltage 78 RPM
Rated Torque 3.1 kg·cm
Stall Torque 18.2 kg·cm
Electrical Properties
Rated Voltage 12 V DC
Rated Current 410 mA
Stall Current 1.5 A
Physical Properties
Shaft Diameter 6 mm
Weight 196 g
Recommended Wire Size (Motor) 20 - 25 AWG
Gearbox Specifications
Gearbox Type Planetary
Gear Ratio 50 801895 : 1
Number of Gear Trains 3
Maximum Strength of Gears 30 kg·cm
Shaft Maximum Axial Load 35 N
Shaft Maximum Radial Load 25 N
Backlash Error
Encoder Specifications
Encoder Resolution 360 CPR
Connector Type E4P
Current Consumption Min 27 mA
Supply Voltage Min 4.5 V DC
Supply Voltage Max 5.5 V DC
The 3263E DC motor connects to either of the following controllers:

If you decide to use the 1065, you can connect the encoder directly into its encoder input. If you decide to use the 1064, you'll also need one of the following devices to read your encoder:

You'll need to solder wires to the contacts of the motor in order to connect it to a controller.
