The 3258E is a 12 volt gear motor, generating 1.53 Kg-cm of torque at 365 RPM. While this motor is small and inexpensive, it is also aggressive- less efficient than the others, but very powerful for its size.

This motor comes equipped with an E4P US Digital Encoder, which keeps track of the motor's rotation, allowing you to control your motor precisely.

This family of motors (3258, 3259, 3260) have the same gearbox type and mounting metrics as the (3254, 3255, 3256, 3257) family of motors.

The 3258E DC motor connects to either of the following controllers:

• 1064 - PhidgetMotorControl HC
• 1065 - PhidgetMotorControl 1-Motor

If you decide to use the 1065, you can connect the encoder directly into its encoder input. If you decide to use the 1064, you'll also need one of the following devices to read your encoder:

• 1047 - PhidgetEncoder HighSpeed 4-Input
• 1057 - PhidgetEncoder HighSpeed

You'll need to solder wires to the contacts of the motor in order to connect it to a controller.

• 3032 – E4P Encoder Cable

• 3258 - 12V/1.5Kg-cm/365RPM 10:1 DC Gear Motor
• 3259E - 12V/2.4Kg-cm/202RPM 18:1 DC Gear Motor w/ Encoder
• 3260E - 12V/6.1Kg-cm/73RPM 50:1 DC Gear Motor w/ Encoder

• DC Motor and Controller Primer
• Encoder Primer
• Mechanical Drawing

The torque this motor produces when it stalls exceeds the rated strength of the gearbox. This means that stalling or very heavily loading this motor can cause serious damage to the gearbox. To avoid damage, avoid sudden loads or any load higher than the Maximum Strength of Gears spec.
